Estadio

Miguel Milá
1992

Estadio

Miguel Milá | 1992

Originally designed for the 1992 Olympic Games in Barcelona, this elegant crown of light ennobles a public space. Conceptually, it is reminiscent of the huge cast iron chandeliers with a sequence of candles often seen in medieval castles and cathedrals. The frame is a tubular structure the visible sides of which are made of sections of glass blocks.


Safe payment Shipping insurance included Installment payment option Care instructions

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 105 cm / 41.3"

This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 93 kg / 205 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
12 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 105 cm / 41.3"

Junction Box adaptor included Ø 11,7 cm / 4.6". This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 93 kg / 205 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
12 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 150 cm / 59"

This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 158 kg / 348.3 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
18 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 150 cm / 59"

Junction Box adaptor included Ø 11,7 cm / 4.6". This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 158 kg / 348.3 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
18 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 250 cm / 98.4"

This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 330 kg / 727.5 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
24 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Dimension plane


Overview

Black metal structure with stainless steel structure hanging system of 1 or 3 supports and satin nickel ceiling plate.
Glass block lampshade.

Ø 250 cm / 98.4"

Junction Box adaptor included Ø 11,7 cm / 4.6". This fixture must be mounted or supported independently of a Junction Box (UL market).
Weight : 330 kg / 727.5 lb
Electrical cable length: 4 m / 157.5"

Light sources

Recommended light source (not included)
24 x LED bulb: 12W
Other light sources: Max.75 W.
Input voltage: 100, 120, 230 Vac.
(50 Hz / 60 Hz)According to destination..
Lampholder: E26 (Max. height155 mm / 6.1")
.

Available modifications

Other ring dimensions.

Other structure shapes.

Lower diffusers.

Compositions of two or more rings one on top of another.

We offer the possibility of adapting our products to the requirements of your contract project, modifying them to your needs.
Contact us to request your customisation.
