Cirio Chandelier

Antoni Arola | 2015

Cirio Chandelier pools a large body of light into a focal axis that stands out from the surrounding area. Its dense array of concentric rings, from which twenty, thirty and even forty light sources may be hung thanks to the enlargeable diameter of the structure, gives off a warm, powerful light with a striking visual impact.


Safe payment Shipping insurance included Installment payment option Care instructions

Dimension plane


Overview

Capsule with LED module, translucent white diffuser and heat sink with black matte finish.
3 lampshade options: white porcelain, white opal glass and polished brass.

Black aluminium circular structure ø 100 cm / 39.4” for 20 light sources.
Adjustable black metallic circular canopy + equipment. Dimming 1-10V. (Not included external dimmer switch 1-10V).
2 hanging system options: direct cable to ceiling plate or direct cable to ceiling.

Suitable for Junction Box (UL market).
Weight (with porcelain lampshade): 25 kg / 55.1 lb

Weight lampshades: porcelain: 0,5 kg / 1.1 lb, glass: 0,6 kg / 1.3 lb , brass:0,3 kg / 0.7 lbElectrical cable length: 5 m / 196.9"

Light sources

Light sources included (dimmable)
20 x Built-in LED
Output 5,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz).According to destination..
CCT: 2.700 K
CRI: 90
Useful life: 40.000 h
Luminous flux: Porcelain 3.280 lm / Glass 11.180 lm / Brass 3.520 lm

Dimension plane


Overview

Capsule with LED module, translucent white diffuser and heat sink with black matte finish.
3 lampshade options: white porcelain, white opal glass and polished brass.

Black aluminium circular structure ø 130 cm / 51.2” for 30 light sources.
Adjustable black metallic circular canopy + equipment. Dimming 1-10V. (Not included external dimmer switch 1-10V).
2 hanging system options: direct cable to ceiling plate or direct cable to ceiling.

Suitable for Junction Box (UL market).
Weight (with porcelain lampshade): 35 kg / 77.2 lb

Weight lampshades: porcelain: 0,5 kg / 1.1 lb, glass: 0,6 kg / 1.3 lb , brass:0,3 kg / 0.7 lbElectrical cable length: 5 m / 196.9"

Light sources

Light sources included (dimmable)
30 x Built-in LED
Output 5,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz).According to destination..
CCT: 2.700 K
CRI: 90
Useful life: 40.000 h
Luminous flux: Porcelain 4.920 lm / Glass 16.770 lm / Brass 5.280 lm

Dimension plane


Overview

Capsule with LED module, translucent white diffuser and heat sink with black matte finish.
3 lampshade options: white porcelain, white opal glass and polished brass.

Black aluminium circular structure ø 160 cm / 63" for 40 light sources.
Adjustable black metallic circular canopy + equipment. Dimming 1-10V. (Not included external dimmer switch 1-10V).
2 hanging system options: direct cable to ceiling plate or direct cable to ceiling.

Suitable for Junction Box (UL market).
Weight (with porcelain lampshade): 50 kg / 110.2 lb

Weight lampshades: porcelain: 0,5 kg / 1.1 lb, glass: 0,6 kg / 1.3 lb , brass:0,3 kg / 0.7 lbElectrical cable length: 5 m / 196.9"

Light sources

Light sources included (dimmable)
40 x Built-in LED
Output 5,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz).According to destination..
CCT: 2.700 K
CRI: 90
Useful life: 40.000 h
Luminous flux: Porcelain 6.560 lm / Glass 22.360 lm / Brass 7.040 lm

We offer the possibility of adapting our products to the requirements of your contract project, modifying them to your needs.
Contact us to request your customisation.
