Cirio Lineal
2010
Cirio Lineal
Biographies
Antoni Arola
Antoni Arola was awarded the Spanish National Design Prize in 2003, and he is recognised as one of the most outstanding members of Spanish design. His common-sense approach has allowed him to create a range of brilliant designs, from a perfume bottle or a lamp, to large scale interior design projects. Arola finds both symbolism and particular a way of understanding the universe through foreign cultures, such as African ones, which he incorporates into his work and his daily life. His works also show his sculptural savoir-faire, his love for drawing and his interest for contemporary art.
Cirio Lineal is a straight section from which five Cirio lamps are hung in succession. They are modular and can be arranged in long rows or in the straight sections of Cirio Oval, using as many lamps as necessary by fitting successive structures together.
Dimension plane
Overview
3 lampshade options: white porcelain, white opal glass and polished brass.
Matte black aluminium structure.
Rectangular matte black metallic canopy with built-in equipment. Suitable for dimming systems 1-10V. (Not included external dimmer switch).Suitable for Junction Box (UL market).
Weight(with canopy and porcelain lampshade): 7,5 kg / 16.5 lb
Electric cable length: 5 m / 196.9"
Light sources
Light sources included (dimmable):
5 x Built-in LED:
Output 7,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: Porcelain: (5) 1.110 lm / (10) 2.220 lm. Glass: (5) 3.275 lm / (10) 6.550 lm. Brass: (5) 1.185 lm / (10) 2.370 lm lm
Input voltage: 120 ~ 277 Vac.
(50 Hz / 60 Hz). Según destino.
Dimension plane
Overview
3 lampshade options: white porcelain, white opal glass and polished brass.
Matte black aluminium structure.
Rectangular matte black metallic canopy with built-in equipment. Suitable for dimming systems 1-10V. (Not included external dimmer switch).
Weight(with canopy and porcelain lampshade): 12 kg / 26.5 lb
Electric cable length: 5 m / 196.9"
Light sources
Light sources included (dimmable):
10 x Built-in LED:
Output 7,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: Porcelain: (5) 1.110 lm / (10) 2.220 lm. Glass: (5) 3.275 lm / (10) 6.550 lm. Brass: (5) 1.185 lm / (10) 2.370 lm lm
E.E.C. F.
Input voltage: 120 ~ 277 Vac.
(50 Hz / 60 Hz). Según destino.
Dimension plane
Overview
3 lampshade options: white porcelain, white opal glass and polished brass.
Matte black aluminium structure.
Rectangular matte black metallic canopy with built-in equipment. Suitable for dimming systems 1-10V. (Not included external dimmer switch).
Weight(with canopy and porcelain lampshade): 16,5 kg / 36.4 lb
Electric cable length: 5 m / 196.9"
Light sources
Light source included (dimmable):
15 x Built-in LED:
Output 7,7W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: Porcelain: (5) 1.110 lm / (10) 2.220 lm. Glass: (5) 3.275 lm / (10) 6.550 lm. Brass: (5) 1.185 lm / (10) 2.370 lm lm
E.E.C. F.
Input voltage: 120 ~ 277 Vac.
(50 Hz / 60 Hz). Según destino.
Available modifications
Other structure lenghts.
