HeadHat Bowl

Equipo Santa & Cole

2013

HeadHat Bowl

Biographies

Santa&Cole_Team-2

Equipo Santa & Cole

Comprising the people who work in Santa & Cole s technical department, led by the editors, the Santa & Cole Team s signature is featured in all our own designs. Some examples are the Trípode G5 lamp (1997), the HeadLed system (2013), the Arne streetlamp (2013) and its indoors version the Arne Domus (2015), the Sisisí system (1994) and the Básica lamp (1984), to name a few.

Read more

Equipo Santa & Cole

 |  2013
Pendant lamps

At Santa & Cole we have developed a LED system that adapts to different shades, just as the Edison thread does. Hence, a single head can be combined with various hats. The HeadHat Bowl series features handmade ceramic shades and is ideal for lighting specific surfaces or points of reference. Very convenient, very simple and very efficient.


Dimension plane


Overview

Capsule with LED module, translucent white diffuser and heat sink with matte black finish.
2 lampshade options: white or black ceramic shade with matte finish interior and gloss exterior.
White or black surface-mounted metal circular canopy with matte finish.

Suitable for dimming 1-10V. Not included external dimmer switch 1-10V.

Suitable for Junction Box (American version).
Electric cable length: 3 m / 117.9"
Weight: 1.6 kg / 3.52 lib

Light sources

Light sources included: Built-in LED:. Output 7,7 W / Input: 90 ~ 305 Vac. (50 Hz / 60 Hz). According to destination.
CCT: 2.705 K
CRI: 90
Lifetime: 40.000 h

Dimension plane


Overview

Capsule with LED module, translucent white diffuser and heat sink with matte black finish.
2 lampshade options: white or black ceramic shade with matte finish interior and gloss exterior.
White or black surface-mounted metal circular canopy with matte finish.

Suitable for dimming 1-10V. Not included external dimmer switch 1-10V.

Suitable for Junction Box (American version).
Electric cable length: 3 m / 117.9"
Weight: 1.1 kg / 2.42 lib

Light sources

Light sources included: Built-in LED:. Output 7,7 W / Input: 90 ~ 305 Vac. (50 Hz / 60 Hz). According to destination.
CCT: 2.705 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 633 lm

We offer the possibility of adapting our products to the requirements of your contract project, modifying them to your needs. All customisations shall be studied upon request respecting the minimum quantity required. Contact us for customisations inqueries.

    HeadLed_Floron_HEF02_HEFD02_HEFD02-DALI-O1-O1-O1

    Circular metal canopy: white surface dimmable dali.

    HeadLed_Floron_HEF02_HEFD02_HEFD02-DALI-O1-O1-O1

    Circular metal canopy: white surface dimmable 1-10v.

    HeadLed_Floron_HEF01_HEFD01_HEFD01-DALI-O1-O1

    Circular metal canopy: black surface dimmable dali.

    HeadLed_Floron_HEF01_HEFD01_HEFD01-DALI-O1-O1-O1

    Circular metal canopy: black surface dimmable 1-10v.

    headhat_bowl_L_pantalla_ceramica_negra_HATL11-O1-O1

    Pantalla cerámica negra

    headhat_bowl_L_pantalla_ceramica_blanca_HATL12-O1-O1

    Lampshade: white ceramic.

    HeadLed_Floron_HEF02_HEFD02_HEFD02-DALI-O1-O1-O1

    Circular metal canopy: white surface dimmable dali.

    HeadLed_Floron_HEF02_HEFD02_HEFD02-DALI-O1-O1-O1

    Circular metal canopy: white surface dimmable 1-10v.

    HeadLed_Floron_HEF01_HEFD01_HEFD01-DALI-O1-O1

    Circular metal canopy: black surface dimmable dali.

    HeadLed_Floron_HEF01_HEFD01_HEFD01-DALI-O1-O1-O1

    Circular metal canopy: black surface dimmable 1-10v.

    headhat_bowl_S_pantalla_ceramica_negra_HATS11-O1-O1

    Lampshade: black ceramic.

    headhat_bowl_S_pantalla_ceramica_blanca_HATS12-O1-O1

    Pantalla cerámica blanca
